UV 3200XE Double Beam Spectrophotometer With Xenon Lamp

Optical Design

Double beam with Czerny Turner Monochromator

Spectral bandwidth

0.5, 1, 2, 4, 5 nm

Light source

Xenon lamp [ ash Lamp] 3 years warranty, 5 years life time

Detector

Dual Silicon photodiode

Wavelength Range

190 ~ 1100 nm

Wavelength Accuracy

0.2 nm [ full range 190nm - 1100nm]

Wavelength Repeatability

0.2 nm

Wavelength Resolutions

0.1 nm

Wavelength Scanning Speed

1 to 6000nm/min variable

Wavelength Data Interval

0.1,0.2,0.5,1.0,2.0,5.0,10

Photometric Range

-4 to 4.0A

Photometric Accuracy

0.006A@2.0A ,0.004A@1.0A ,0.002A@05A , 0.3%

Photometric Noise

0.00003 Abs RMS@500nm

Photometric Drift

< 0>

Photometric Mode

Absorbance %,Transmittance % log [Abs], Factor Intensity

Photometric Reproducibility

0.001Abs[1.0 Abs]

Baseline Flatness

0.0005 Abs/h

Baseline Stability

<0>

Stray Light

<0>

Accuracy [with sealed solution] EP/BP/TGA

0.010 A [60mg/L K2Cr2O7]

Detector

Dual Silicon photodiode

Sample Cell Holder

10 mm 1-cell holder [Multi cell up to 8]

Software

Complies with the requirement of 21CFR Part 11 with GLP/GMP function

Storage

64GB [built-in], unlimited expansion [USB storage, SD card, network storage device]

Power

100 ~ 240 V AC, 50/60 Hz, 100 W

Dimension

600X450X200mm
